High Quality Carbide Rods with Two Helical Coolant Holes

High Quality Carbide Rods with Two Helical Coolant Holes
High Quality Carbide Rods with Two Helical Coolant HolesHigh Quality Carbide Rods with Two Helical Coolant HolesHigh Quality Carbide Rods with Two Helical Coolant HolesHigh Quality Carbide Rods with Two Helical Coolant HolesHigh Quality Carbide Rods with Two Helical Coolant Holes
group name
Tungsten Carbide Rods
Min Order
1 piece
Delivery clauses under the trade mode
FOB, CIF, EXW
Acceptable payment methods
T/T, L/C, PayPal, Westem Union
update time
Fri, 27 Sep 2019 12:48:57 GMT

Paramtents

  • Description h6 ground carbide rods for making drill

  • Type Blank rods or ground h6

  • Specification Standard 1.2~32or Customized

  • Main Grade GH10 and GH12

  • Shape Solid Cylinder carbide

  • Feature Good Wear Resistance, HIP Sintering, long lifespan

  • Material 100% Virgin Raw Material

  • Packing Plastic tube +5 layer outer carton

Packging & Delivery

  • Min Order1 piece

Briefing

10% Coablt carbide rods recommanded for making drill, endmill, burr, specially for cutting non-ferrous metal and graphite.

Detailed




Grade Introduction
GradeISOGrain size
(μm)
Cobalt Content
(%)
Hardness
(HRA)
Density
(g/cm3)
T.R.S
(N/mm2)
GH10FK05-K100.4693.514.83800
Ultrafine grain size, with amazing wear resistance. High wear resistance endmill and engraving tools are recommended suitable for cutting PCB and composite material.
GH15FK10-K200.48.59314.523800
Ultrafine grain size,with good wear resistance. High wear resistance endmill and engraving tools are recommended suitable for cutting PCB and plastic.
GH25FK20-K400.41292.514.104200
Ultrafine grain size, higher Co content, with excellent hardness and toughness. Endmill and reamer are recommended.
Excellent performance for finishing. Especially suitable for cutting steel  ( HRC: 45-55 ) ,AI alloy and Ti alloy.
GH6AK151.06.092.514.952450
Drill, endmill and burr are recommended. Especially suitable for cutting
non-ferrous  metal and graphite(coating is needed).
GH20K20-K400.810.391.714.403500
Drill and endmill are recommended. Suitable for cutting general steel(HRC<48),grey cast iron, stainless steel and heat resistant alloy.
GH10.2YL10.20.610.292.314.303800
Drill and endmill are recommended. Especially suitable for cutting stainless steel, heat resistant alloy, cast iron.

øDTol.of Length
(+0~+5)
ødTKøPitch ( ±0.5°)a
PTol.
33300.401.7016.32-0.32+0.330.15
43300.602.2021.77-0.43+0.450.15
53300.702.6027.21-0.54+0.560.15
63300.702.6032.65-0.65+0.670.15
73301.003.7038.09-0.76+0.780.15
83301.004.0043.53-0.86+0.890.15
93301.404.8048.97-0.97+1.000.20
103301.404.8054.41-1.08+1.110.20
113301.405.3059.86-1.19+1.220.30
123301.406.2565.30-1.30+1.340.30
133301.756.5070.74-1.40+1.450.37
143301.757.1076.18-1.51+1.560.40
153301.757.7081.62-1.62+1.670.40
163301.758.3087.06-1.73+1.780.40
173301.758.9092.50-1.84+1.890.45
183302.009.5597.95-1.94+2.000.50
193302.0010.10103.39-2.05+2.120.50
203302.0010.40108.83-2.16+2.230.50
213302.0011.15114.27-2.27+2.340.50
223302.0011.60119.71-2.38+2.450.50
233302.0012.20125.15-2.48+2.560.50
243302.0012.80130.59-2.59+2.670.50
253302.0013.30136.03-2.70+2.780.50

                                                                                                                                           Unit(mm)

GH
Standard
Unground  ØD(mm)Ground  ØD(mm)
RangeTol.RangeTol.
3≤øD≤6+0.60 ~+1.003≤øD≤25h6
6<øD≤24+0.70 ~+1.10
øD=25+0.80 ~+1.20
Ød (mm)TKø (mm)
RangeTol.RangeTol.
0.40≤ød≤0.90±0.10TKø≤4.00+0~-0.40
0.90<ød≤1.70±0.154.00+0~-0.60
ød=1.75±0.205.00+0~-0.80
ød=2.00±0.2510.10+0~-1.00

øDTol.of Length
(+0~+5)
ødTKøPitch ( ±0.5°)a
PTol.
63300.502.2022.46-0.39+0.400.15
83300.652.7029.95-0.53+0.540.15
103300.803.5037.44-0.66+0.670.20
123300.904.2044.93-0.79+0.800.30
143301.004.7052.42-0.92+0.940.40
163301.205.5059.90-1.05+1.070.40
183301.406.3067.39-1.18+1.210.50
203301.507.1074.88-1.31+1.340.50

                                                                                                                                           Unit(mm)

GH
Standard
Unground  ØD(mm)Ground  ØD(mm)
RangeTol.RangeTol.
6≤øD≤20+1.10 ~+1.506≤øD≤20h6
Ød (mm)TKø (mm)
RangeTol.RangeTol.
0.40≤ød≤0.60±0.10TKø≤2.20+0~-0.40
0.60<ød≤0.90±0.152.20+0~-0.60
0.90<ød≤1.20±0.202.70+0~-0.80
1.20<ød≤1.50±0.25TKø=7.10+0~-1.00



 Delivery time

For samples: 5-7 days
For formal orders:10 -15 days


Payment
T/T, Western Union, PayPal, Money Gram, etc.
Payment≤1000 dollars, 100% in advance. Payment≥10000 dollars, 30% T/T in advance ,balance before shipment.

Packing
Standard carton

Shipment
DHL, FedEx, TNT, UPS, EMS, etc.

Any port in China.
